The Mitutoyo ABSOLUTE digital caliper delivers accurate, repeatable outside dimension, inside dimension, depth and step measurements with accuracy and unrestricted speed. The caliper’s slide and jaws are constructed of hardened stainless steel with optional carbide-tipped jaws available. The impact-resistant, easy-to-ready LCD display is highly durable and provides large character height (9.0mm in height) which improves readability.

• Available in Metric and Inch/Metric models
• Available with or without SPC output capabilities
• Carbide-tipped jaws are available
• Thumb roller included only on calipers up to and including 300mm/12” models
• ABSOLUTE (ABS) linear scale eliminates the need for setting the origin point every time the micrometer is powered on; overspeed errors are also eliminated
• Stainless steel construction protects caliper components and ensures accurate performance for longer duration
• SPC output function allows for quick and easy data management in real time
• Functions include Origin Set, Zero-Setting, Data Output and inch/mm conversion (on inch/metric models only)
• Alarm: Low Voltage, counting value composition error
• Supplied in a fitted plastic case; 1000mm/40” model is supplied in a wooden case

OTHER STOCK MITUTOYO DIGIMATIC CALIPERS:

Mitutoyo 500-195-30 - 4" ABSOLUTE AOS Digimatic Caliper

Mitutoyo 500-762-20  - 6" ABSOLUTE Digimatic Caliper w SPC, IP67 Coolant Proof

Mitutoyo 500-752-20 - 6" ABSOLUTE Digimatic Caliper IP67 Coolant Proof  IP67

Mitutoyo 500-171-30 -  6" ABSOLUTE AOS Digimatic Caliper  SPC

Mitutoyo 500-197-30 - 8" ABSOLUTE AOS Digimatic Caliper CD-8ASX

Mitutoyo 500-196-30 - 6" ABSOLUTE AOS Digimatic Caliper CD-6ASX

Mitutoyo 573-721-20 - 6"  ABSOLUTE Digimatic Point Caliper SPC IP67
