• Non-rotating device
  350-261-30,350-361-30

The non-rotating device provides no radial torsion on the workpiece surface so that workpiece wear and deformation are minimized.


Technical Data
Accuracy* ±2ìm Metric model
± .0001" Inch / Metric model
* Excluding quantizing error
Resolution: 0.001mm or .00005"/0.001mm
Display: LCD
Battery: SR44 (1 pc) 938882
Battery life: Approx. 3 years under normal use
Dust/Water protection level: IP65
350-281-30, 350-382-30, 350-283-30, 350-284-30, 350-261-30
350-381-30, 350-382-30, 350-383-30, 350-384-30, 350-361-30
Function
Preset, inch/mm conversion (inch/mm models)
Alarm: Low voltage, Counting value composition error
Function Lock
2 Presets
Optional Accessories
05CZA662: SPC cable with data switch (1m / 40")
05CZA663: SPC cable with data switch (2m / 80")

Parts Break Down
