Balax 11844-010 - 8-36 BXB BH4 Form Tap Bottom Bright USA - Pkg 12 ea
Hover over image to zoom
)
Product Description
8-36 BH3 THREDFLOER
Specifications
| Category | Thredfloers |
| Series | BOTTOM |
| # of Grooves | 1 |
| Chamfer | 2.5 |
| Blank Name | ANSI CNC |
| Overall Length | 2-1/8 |
| Thread Length | .450 |
| Neck Length | 3/4 |
| Shank Diameter | .168 |
| Square | .131 |
| Square Length | 1/4 |
Pre-Tap Hole Sizes
| 55% Thread | 0.153 |
| 65% Thread | 0.151 |
| 75% Thread | 0.150 |
| 85% Thread | 0.149 |
Recommended Limits for 8-36 Thread
| CLASS 2B | H4, H5 |
| CLASS 3B | H3, H4 |
Possible Gage Members for 8-36 Thread
| 90140 | GO ELEMENT |
| 90142 | 2B NO GO ELEMENT |
| 90144 | 3B NO GO ELEMENT |
| 90146 | 2B SET |
| 90148 | 3B SET |
