Balax 11743-010 - 8-32 BXB STI BH3 Form Tap Bright - USA ** One Piece Price, Discount starts at 12 Ea**
Hover over image to zoom
)
Product Description
Balax 11743-010 - 8-32 BXB STI BH3 Form Tap Bright - USA
BRIGHT FINISH
Specifications
| Category | Thredfloers |
| Series | STI |
| # of Grooves | 1 |
| Chamfer | 2.5 |
| Blank Name | #12 ANSI CNC |
| Overall Length | 2-3/8 |
| Thread Length | .600 |
| Neck Length | 15/16 |
| Shank Diameter | .220 |
| Square | .165 |
| Square Length | 9/32 |
Pre-Tap Hole Sizes
| 55% Thread | 0.191 |
| 65% Thread | 0.190 |
| 75% Thread | 0.188 |
| 85% Thread | 0.187 |
Recommended Limits for 8-32 Thread
| CLASS 2B STI | H2, H3 |
| CLASS 3B STI | H2 |
Possible Gage Members for 8-32 Thread
| 90498 | STI GO ELEMENT |
| 90500 | STI 2B NO GO ELEMENT |
| 90501 | STI 3B NO GO ELEMENT |
| 90502 | STI 2B SET |
| 90503 | STI 3B SET |
