Balax 11046-010 - 5-40 BXB BH6 Form Tap Bottom Bright USA - Pkg 12 ea

Balax 11046-010 - 5-40 BXB BH6 Form Tap Bottom Bright USA - Pkg 12 ea
Image 1

Hover over image to zoom

Click to enlarge
RRP: $28.37
$19.75 (You save $8.62)
SKU:
11046-010
Minimum Purchase:
12 unit(s)

 Product Description



Balax 11046-010 - 5-40 BXB BH6 Form Tap Bottom Bright USA

Specifications

Category Thredfloers
Series BOTTOM
# of Grooves 0
Chamfer 2.5
Blank Name ANSI
Overall Length 1-15/16
Thread Length .626
Neck Length 0
Shank Diameter .141
Square .110
Square Length 3/16

Pre-Tap Hole Sizes

55% Thread 0.116
65% Thread 0.115
75% Thread 0.114
85% Thread 0.113

Recommended Limits for 5-40 Thread

CLASS 2B H4, H5
CLASS 3B H3, H4

Possible Gage Members for 5-40 Thread

90090 GO ELEMENT
90092 2B NO GO ELEMENT
90094 3B NO GO ELEMENT
90096 2B SET
90098 3B SET
