Balax 11043-010 - 5-40 BXB BH3 Form Tap Bottom Bright USA - Pkg 12 ea
Hover over image to zoom
)
Product Description
Balax 11043-010 - 5-40 BXB BH3 Form Tap Bottom Bright USA
Specifications
| Category | Thredfloers |
| Series | BOTTOM |
| # of Grooves | 0 |
| Chamfer | 2.5 |
| Blank Name | ANSI |
| Overall Length | 1-7/8 |
| Thread Length | .563 |
| Neck Length | 0 |
| Shank Diameter | .141 |
| Square | .110 |
| Square Length | 3/16 |
Pre-Tap Hole Sizes
| 55% Thread | 0.104 |
| 65% Thread | 0.103 |
| 75% Thread | 0.102 |
| 85% Thread | 0.102 |
Recommended Limits for 4-48 Thread
| CLASS 2B | H4, H5 |
| CLASS 3B | H3, H4 |
Possible Gage Members for 4-48 Thread
| 90080 | GO ELEMENT |
| 90082 | 2B NO GO ELEMENT |
| 90084 | 3B NO GO ELEMENT |
| 90086 | 2B SET |
| 90088 |
3B SET |
