Balax 10522-010 - 3-48 BH2 BXB Form Tap Bottom Bright USA - Pkg 12 ea
Hover over image to zoom
)
Product Description
Balax 10522-010 - 3-48 BH2 BXB Form Tap Bottom Bright USA - Pkg 12 ea
Specifications
| Category | Thredfloers |
| Series | BOTTOM |
| # of Grooves | 0 |
| Chamfer | 2.5 |
| Blank Name | ANSI |
| Overall Length | 1-13/16 |
| Thread Length | .500 |
| Neck Length | 0 |
| Shank Diameter | .141 |
| Square | .110 |
| Square Length | 3/16 |
Pre-Tap Hole Sizes
| 55% Thread | 0.090 |
| 65% Thread | 0.089 |
| 75% Thread | 0.088 |
| 85% Thread | 0.088 |
Recommended Limits for 3-48 Thread
| CLASS 2B | H4, H5 |
| CLASS 3B | H2, H3 |
Possible Gage Members for 3-48 Thread
| 90050 | GO ELEMENT |
| 90052 | 2B NO GO ELEMENT |
| 90054 | 3B NO GO ELEMENT |
| 90056 | 2B SET |
| 90058 | 3B SET |
