Balax 10286-011 - 2-56 BH6 BXB Form Tap Bottom Nitride USA - Pkg 12 ea
Hover over image to zoom
)
Product Description
Balax 10286-011 - 2-56 BH6 BXB Form Tap Bottom Nitride USA - Pkg 12 ea
BRIGHT FINISH
In Stock
66 PCSSpecifications
| Category | Thredfloers |
| Series | BOTTOM |
| # of Grooves | 0 |
| Chamfer | 2.5 |
| Blank Name | ANSI |
| Overall Length | 1-3/4 |
| Thread Length | .438 |
| Neck Length | 0 |
| Shank Diameter | .141 |
| Square | .110 |
| Square Length | 3/16 |
Pre-Tap Hole Sizes
| 55% Thread | 0.081 |
| 65% Thread | 0.080 |
| 75% Thread | 0.079 |
| 85% Thread | 0.078 |
Recommended Limits for 2-56 Thread
| CLASS 2B | H3, H4 |
| CLASS 3B | H2, H3 |
Possible Gage Members for 2-56 Thread
| 90030 | GO ELEMENT |
| 90032 | 2B NO GO ELEMENT |
| 90034 | 3B NO GO ELEMENT |
| 90036 | 2B SET |
| 90038 | 3B SET |
| 90580 | PRE-PLATE GO ELEMENT |
| 90581 | PRE-PLATE NO GO ELEMENT |
| 90980 | PRE-PLATE SET |
