Balax 01002-010 - 0.9 X 0.225 BH2 UNM Miniature Form Tap Bottom USA Mfg

Balax 01002-010 - 0.9 X 0.225 BH2 UNM Miniature Form Tap Bottom USA Mfg

Hover over image to zoom

RRP: $104.97
$69.00 (You save $35.97)
SKU:
01002-010
Minimum Purchase:
12 unit(s)

 Product Description



Product image

EDP#: 01002-010



0.9MMx.225 BH2 MINIATURE THREDFLOER

BRIGHT FINISH

Specifications

Category Thredfloers
Series MINIATURE
# of Grooves 0
Chamfer 2.5
Blank Name ANSI
Overall Length 1-5/8
Thread Length .250
Neck Length 0
Shank Diameter .141
Square .110
Square Length 3/16


Pre-Tap Hole Sizes

55% Thread 0.0323
65% Thread 0.0319
75% Thread 0.0314
85% Thread 0.0311

Recommended Limits for 0.9MMx.225 Thread

CLASS UNM H2

Possible Gage Members for 0.9MMx.225 Thread

90528 MINIATURE GO ELEMENT
90530 MINIATURE NO GO ELEMENT
90532 MINIATURE SET
